PRECISION HUMIDITY AND TEMPERATURE GENERATOR HCAL 1104U

Available

Phone Number

08048035791

Please keep 0 before dialling the number.

Email Address marketing1@sansel.net

Mon-Thu: 10 AM - 2 PM • Fri: 3 PM - 7AM

Other Website Visit our other website

Address No.1/46,Ganga Nagar,M.M.D.A Colony Maduravoyal,Chennai-600095

Chennai, India, 600095

Description

Model HCAL 1104U Control Range* 10 to 50°C / 5 to 95 % RH* Resolution 0.01 °C / %RH Stability** Better than ± 0.05 °C / 0.2 % ** Uniformity** ± 0.2 °C / 0.3 % RH ** Display 7” True colour TFT LCD Display with Touch screen Test sensor insert port Inter changeable Acrylic door Provided on front side of the chamber with pg21 gland (cable or sensor size range from 13 to 18mm) x 3nos External Humidifier Water tank capacity 6 liters (approx.) (NOTE : 3 liter filling is enough for our application) Humidifier Liquid Distilled water Humidifying Time 2 %RH / sec (50 to 90 % RH) Dehumidifying Time 6 %RH / sec (50 to 10 % RH) Test chamber area 230mm DIA x 170mm D(Approx) Power supply 230V AC ± 10% / 50Hz (Optional 110V AC) Power Consumption 1000 VA Construction Inner chamber SS 310 / outer MS powder coating Overall Dimension 436mm L x 676mm W x 368mm H (Approx) Instrument Weight 44 kg(without Accessories) + 6 kg (standard accessories) (Approx.) Note: * Range cover based on Temperature vs Humidity chart given on page 3 ** @ 25°C chamber temperature The above specification is tested @ Ambient 25°C
