Description

Product details

Model: FI 593 Display : 16 Character X 2 Line LCD Display Input (factory settable): 4-20mA / 0-20mA / 0-2.5V / 0-5V / 0 - 10V / 0 - 75mV (any One) Accuracy at 25°C: ± 0.1% of FS Resolution : 1 / 0.1 / 0.01 (any One User Selectable) Display Modes: Flow Rate (FR) & Total Flow (TF) Display Range: 0 - 9999 (4 Digits) for FR , 0 - 99999999(8 Digits) for TF Units: m³ , Liter, Gallons (Selectable) Voltage Drop: 1 V Maximum (Applicable only for current input models) Input Impedance: 18K Ohms (Applicable only for voltage input models) Conversation Modes:Linear, Square Root (User Selectable) Flow Rate Time Base: Seconds, Minutes, Hours (Selectable) Sensor Supply: 24 V DC / 100mA Max. Power Supply: 90 to 270 V AC Operating Environment: 0 to 60°C / 5 to 95 % RH Non Condensing Frequency : 50 / 60 Hz
